Degremont Technologies – Heliantis™ Solar Sludge Drying

A SUBSIDIARY OF SUEZ ENVIRONNEMENT

About the Company:

Infilco Degremont’s Biosolids solutions span a broad spectrum of applications. Infilco offers a complete line of industry-leading technologies for biosolids digestion, dewatering, drying and thermal oxidation. Infilco understands the careful planning needed to design and construct this portion of the plant. Consult Infilco’s specialists to find the most appropriate solution for your specific treatment requirement.

About the Solution:

Heliantis™ transforms any type of dewatered sludge (15% minimum dry content) into a dry, granulated product with a dry-solids content that can be adjusted within a range of 35% to 85%. Using the sun as the main energy source, the sludge is dried in a greenhouse and a scarifying machine turns over and breaks up the sludge into carbon-neutral and odorless granules, for eventual agricultural reuse or thermal energy production using co-incineration.

Degremont Technologies 8007 Discovery Drive P.O. Box 71390 Richmond, VA USA 804-756-7600 Visit Company Website

Solution Type

  • Active Solids Drying

Vendor

  • Equipment Vendor

Product

  • Concentrated Nutrients

Problem

  • GHG
  • Nitrogen
  • Odor
  • Pathogens
  • Storage

To view additional information about this vendor, click below.

Solution Strengths, Weaknesses and Critical Indicators

Active Drying Technologies:

  • Produce a marketable product, dry manure solids, and reduce transportation costs
  • Require energy to reduce water content and dry manure solids, purchased energy cost are an issue
  • Require operator attention in excess of other systems due to the risk of combustion
  • Other compounds are released with the water (i.e. ammonia, hydrogen sulfide), and require additional treatment
  • Potential loss of ammonia nitrogen due to volatilization
  • Proven technology for storage reduction, odor control, GHG reduction and pathogen reduction

Newtrient Comments/Opinions:

Evaporation and Drying Technologies:

  • Uses heat to produce either manure with less water or dried manure solids
  • Systems that reduce water in manure use a series of evaporators to sequentially evaporate water from liquid slurries—energy is supplied either by purchased fuel and/or waste heat from other processes
  • Systems that dry separated solids use either a belt or drum to evaporate water from separated solids—energy is supplied either by purchased fuel, electricity and/or waste heat from other processes
  • Chemicals are released with the water (i.e. ammonia, hydrogen sulfide), and this often requires additional treatment such as condensation of the water and/or scrubbing of the chemicals
  • The requirement for purchased energy and costs are a significant concern leading to a tradeoff between input costs and gains in liquid concentration and transportation/market of by-products
Degremont Technologies has been unresponsive to Newtrient's multiple attempts to supplement or validate the information about this technology.
